C10TX
The Konted C10TX is a dual-probe 3-in-1 handheld ultrasound system that combines convex, linear and phased-array cardiac transducers in a single wireless device. With 128 elements and dedicated arrays for abdominal, superficial and cardiac imaging, the C10TX supports whole-body examinations in a highly portable format.
The probe can connect to mobile devices and computers via Wi-Fi or wired connection, and is compatible with iOS, Android and Windows platforms. Typical scan frequencies include convex at 3.5 / 5 MHz, linear at 7.5 / 10 MHz and cardiac at 2.5 / 5 MHz, with corresponding depth ranges of approximately 90–305 mm (convex), 20–100 mm (linear) and 90–160 mm (cardiac), depending on the mode selected.
The C10TX features an IP68 waterproof housing, ultra-lightweight design and internal rechargeable battery that can provide up to approximately 4 hours of continuous scanning with standby times up to several days. It is well-suited for emergency, bedside, anesthesia, vascular access, abdominal, cardiac, lung and superficial applications.
- Dual-probe 3-in-1 handheld ultrasound (convex + linear + cardiac)
- Elements: 128
- Convex frequencies: approx. 3.5 / 5 MHz
- Linear frequencies: approx. 7.5 / 10 MHz
- Cardiac (phased-array) frequencies: approx. 2.5 / 5 MHz
- Typical depth ranges: convex ~90–305 mm; linear ~20–100 mm; cardiac ~90–160 mm
- Whole-body application coverage with a single probe
- Wireless and wired connection options (Wi-Fi / cable)
- Compatibility with iOS, Android and Windows devices
- IP68 waterproof design
- Internal rechargeable battery with working time up to about 4 hours and long standby time
- Ultra-lightweight handheld form factor
- Three transducer types in one device reduce the need for multiple probes
- Supports abdominal, superficial and cardiac imaging for multi-disciplinary use
- Wireless connectivity and mobile-device integration enhance portability and workflow flexibility
- IP68 protection and long battery life suit emergency, outdoor and transport scenarios
Point-of-care whole-body ultrasound including abdominal, cardiac, lung, vascular access, superficial, MSK and emergency imaging in hospitals, clinics and pre-hospital settings.
Manufactured medical device quality standards and supplied with CE/FDA certifications according to manufacturer information.
